287mm Aluminum Spigot Truss 50*3mm Main Tube 16m Span ISO9001

Brand Name : LEDIKA

Model Number : SQS287

Certification : ISO9001

Place of Origin : China

MOQ : 10pcs

Price : negotiation

Payment Terms : T/T, D/P, Western Union

Supply Ability : 50pcs per month

Delivery Time : 15 days upon payment receipt

Packaging Details : Carton packing

Product Name : Spigot Truss

Color : Silver, Black

Span : 16m

Lenght : 0.5-4M

Truss size : 287x287mm

Material : Aluminum 6082-T6

Main Tube : 50*3mm

Brace Tube : 30*2mm

Contact Now

6082-T6 287mm Silver Truss Aluminum Spigot Truss Indoor / Outdoor Events​ ​

Specifications

SQS287 square truss 287*287, it connected by spigot.

Item

Aluminum truss description

Specification

910mm*760mm/760mm*600mm/760mm*520mm/600mm*500mm/500mm*500mm/

450mm*450mm/400mm*400mm/350mm*350mm/300mm*300mm/250mm*250mm/

Tube Size

The main tube 50*3mm , brace is 25*3mm and 25*2mm

Normal length

Each piece truss is 0.5M-4M

Material

Mainly aluminum 6082-T6

Loading capacity

The max loading is 1600KG

Feature

all kinds of truss can be retread and reused, because it have high corrosion resistance,

non-toxic with high technical welder and good quality of alloy aluminum tube. It can help you to save the expenditure.

Other products

square truss , straight truss, circle truss, ladder truss,

spigot truss, bolt truss and other abnormity truss are available

Application fields

hang light, hang speaker, hang LED screen, outdoor performation roof truss, exhibition stand build, stage truss, background truss.

Advantages

1.16 years perfessional stage truss big events experience since 2001.
2. Projects case are cover to all over the world.
3. LEDIKA Brand is famous in many countries and government tender brand.
4. OEM and R&D support.
5. We attend prolight show every year.
6. With material 6082 T6 guarantee certification.
7. Have ISO certification.
8. Honor of experiences worked for 2007 Special Olympic, 2008 Beijing Olympic Games, Asian Games, Shanghai Expo and World Youth Skiing Championships etc.
9. Best quality aluminium truss and stage, strict working production process.
10. Life-time after sales service.
